Indoor / Outdoor High Brightness Slim Stage Rental led Display P6.9 P7.8 P10.4

Ask Lasest Price
Brand Name :	ARISE
Certification :	ISO CE FCC ROHS
Model Number :	Stage Rental led Display P6.9 P7.8 P10.4
Price :	1
Delivery Time :	7
Payment Terms :	TT
Supply Ability :	10000SQM/MONTH

Add to Cart

Product Details
Company Profile

Indoor / Outdoor High Brightness Slim Stage Rental led Display P6.9 P7.8 P10.4

Arise Technology Co., Ltd

Email:gm@ariseled.com; Web:http://www.ariseled.com QQ:2329518805 Skype:ariseled

Technical Specification:

Product Parameters	AR6.9			AR7.8	AR10.4
Pixel Pitch	6.9mm			7.8mm	10.4mm
Pixel Configuration	3-in-1 SMLD 3528			3-in-1 SMD 3528	3-in-1 SMD 3528
Module Resolution	72 x 36			64 x 32	24 x 24
Pixel Per Module	2,592			2,592	576
Module Size	500mm x 250mm			500mm x 250mm	250mm x 250mm
Pixel Density	20,738pixels/㎡			16,384pixels/㎡	9,217pixels/㎡
Recommended Mininum Viewing Distance	7 m			8 m	9 m
Brightness	≥1,200cd/㎡ ≥1,800cd/㎡			≥1,000cd/㎡	≥3,500cd/㎡
Color Temperature	6,000°K - 12,000°K			6,000°K - 12,000°K	6,000°K - 12,000°K
Viewing Angle(H/V)	H:110° / V:100°			H:110° / V:100°	H:110° / V:100°
Cabinet Pixel Matrix	72 x 72	72 x 144		64 x 32	48 x 96
Cabinet Size	500mm x 500mm x 60mm or 500mm x 1,000mm x 60mm			500mm x 1,000mm x 60mm	500mm x 1,000mm x 60mm
Cabinet Material	Extruded Aluminum			Extruded Aluminum	Extruded Aluminum
Cabinet Weight	≈ 6 KG		≈ 12 KG	≈ 12 KG	≈ 12 KG
Colours	281 trillion			281 trillion	281 trillion
Grayscale (Linear)	12 bits			12 bits	12 bits
Brightness Control	100 Levels			100 Levels	100 Levels
Video Frame Rate	≥ 60 Hertz			≥ 60 Hertz	≥ 60 Hertz
Display Refresh Rate	≥ 960 Hertz			≥ 1,000 Hertz	≥ 960 Hertz
Driving Method	1/9			1/8	1/4
Input Voltage (Nomind)	AC 110V / 220V / 110-220V			AC 110V / 220V / 110-220V	AC 110V / 220V / 110-220V
Input Power Frequency	50 / 60 Hertz			50 / 60 Hertz	50 / 60 Hertz
Input Power (Max)	400 W / ㎡			480 W / ㎡	480 W / ㎡
Input Power (Average)	200 W / ㎡			240 W / ㎡	240 W / ㎡
Working Temperature	-20℃-40℃			-20℃-40℃	-20℃-40℃
Storage Temperature	-35℃-85℃			-35℃-85℃	-35℃-85℃
Working Humidity	10%-95%			10%-95%	10%-95%
Lifespan(50% Brightness)	≥100,000 Hours			≥100,000 Hours	≥100,000 Hours
Application	Indoor / Outdoor			Indoor / Outdoor	Indoor / Outdoor
Ingress Protection (Front/Rear)	IP 65 / 43			P 65 / 43	P 65 / 43
Maintenance Mode	Rear			Rear	Rear

Specifications:

1. Slim Stage Rental led Display

2. High Brightness

3.High definition display

VIEWABILITY & VISIBILITY

1.High definition display with superior image quality for an enhanced viewing experience even when viewed from a shorter distance

2.Superb contrast & brightness levels for vivid visuals, images and colours even when viewed in bright daylight.

3.TV studio friendly with high refresh rates providing stable and flicker-free display

4.Advanced Control System allows for better control of any display content with resolution / aspect ratio adjustments;scaling / compressing capability ; and for connection to a multitude of data and video sources

VERSATILITY & RELIABILITY

1.Mesh design with 25%high transparency. Enables multilayer display setup that allow effects like smoke.audio and wind to pass through.Also for building or facade application where natural light can penetrate the display and windows into the building interior-an energy saving setup.

2.Creative setups include curved,circular or wave forms;and irregular profiles around structures.

3.Creative mounts include being hung as curtain wall,ceiling mounted,or stacked with support structure for regular / irregular shapes.

4.Slim profile and light weight modules that are easy to install and maintain as well as to transport and store.

5.Fast rigging system with spring lock mechanism,positioning locators and locking plates for simple,secure and seamless connection between cabinets.

6.High precision extruded aluminum frame that is tough and strong to withstand frequent mobilisation, installation and transportation.

7.Robust mechanical components and electronics assembly to withstand the rigours of demanding operations in varied harsh environments from event to event.

8.Applications:Stage background,main and split screens;Entertainment centers;and Special events.
