DIP 2R1G1B P16 waterproof outdoor full color led display moving
advertising video wall
Square Commercial DIP P16 Outdoor LED Display Billboards 2R1G1B For
Public
Outdoor LED Display DIP Series:
P10 DIP 1R1G1B Outdoor LED Display
P12 DI1R1G1B Outdoor LED Display
P16 DIP 1R1G1B Outdoor LED Display
P16 DIP 2R1G1B Outdoor LED Display
P20 DIP 1R1G1B Outdoor LED Display
P20 DIP 2R1G1B Outdoor LED Display
P25 DIP 2R1G1B Outdoor LED Display
Arise Technology Co., Ltd
Web:http://www.ariseled.com
QQ:1327078259 Skype:ariseled
http://i.youku.com/ariseled
Function:
Excellent visual effect, clear and exquisite,Good flatness.
Easy to clean, welding spots inoxidizable.
Closer look available, better effects without glare and mosaic.
Good viewing angle,No color cast when look from different angles.
Easy to assembly, install and transport with simple packing and
convenient use.
Excellent heat-sinking, high stability, no scrapped lamp.
Part Number | P16 |
Resolution | 16(H)×8(V) |
Pixel Pitch | 16mm(Virtual:8mm) |
LED Configuration | 2R1G1B -DIP |
Pixel Density | 3,906 pixels/ ㎡ |
Module Size | 256×128mm |
Cabinet Size | 1024×768mm, 768×768mm, etc. |
Driving IC | MBI5024 led & IC mounted to 2 PCB design |
Driving Method | Static State, Constant Current |
Weight | 58KG/sq.m. |
Mechanical Ratings |
Hanging Weight Support | 2T |
Surface Flatness | Gap<0.5mm |
Optical Ratings |
Brightness | >8,000cd/ ㎡ |
View Angle | 120°/60° |
Gray Scale | 8bits input, correction with 14bits |
Display COLOR | 16.7M |
Brightness Adjustment | 0～100% 10 level |
Power Supply |
Operation Power | 90～260V 50～60Hz |
Max. Power Consumption | 1200W/ ㎡ |
Average Power Consumption | 350W/ ㎡ |
Control System |
Control Mode | Synchronous display with control PC by DVI |
Frame Update Frequency | 60～85Hz |
Screen Refresh Frequency | 300～1000Hz |
Gamma Correction | -5.0～+5.0 |
Support Input | Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI |
Control Distance | Ethernet cable<120m or Fiber Optic<10Km |
Support VGA Mode | 1024×768, 1280×1024, 1600×1200, 1920×1280 |
Brightness Correction | Pixel, Module, Cabinet |
Environmental |
Operating Temperature | -20°～+60° |
Operating Humidity | 10～95% RH |
Operating Life | 100,000hours |
MTBF | 5000hours |
Protection Level | IP65 |
Out of Control Rate | <0.02% |
Feature :
With High brightness >7500 nits make the display content visible
even under direct sunshine during daytime.
With light sensor for automatic brightness adjustment, make the
brightness suitable for people’s eyes and save electricity cost,
more environment Friendly.
Anti-UV mask, IP65 waterproof design, total outdoor use
application.
Large viewing angle , full color, high color uniformity and clear
image, bring you a vivid audio visual effect.
Arise Technology Co., Ltd. is a high-tech company dedicated in
providing professional LED displays and comprehensive
optoelectronic solutions.
Arise Technology owns strong execution, brilliant development
strategies and programs, sustainable creation based on market
demand. We spare no effort to provide customers with
market-oriented innovative products with good reliability, suitable
solutions and all-round service. Our main products includes indoor
and outdoor full color fixed installation LED display, indoor and
outdoor rental LED displays, LED Mesh/LED curtain displays, LED
advertising player displays, floor LED displays, stadium/perimeter
LED displays, creative LED displays, mobile LED displays, flexible
LED displays, transparent LED displays, high-resolution full color
LED display, customized LED displays, and the whole display system
and equipment. We are ready to providing LED display solutions for
oversea and domestic advertisement media, building advertising and
lighting, municipal administration, hospital, hotel, bank, traffic,
sports, entertainment, show, exhibition, etc.
We Arise Technology regard integrity in company staff, customers
and suppliers as the enterprise foundations, market demands as the
guide. We guarantee quality with profession and dedication and use
enterprise culture to fill our brand. We keep striving, forging
ahead, creating to provide customer with strong and unremitting
support and backup.
We Arise Technology also have more LED displays for your projects:
Category Pixel Pitch(mm)
1. Outdoor Fix Installation LED Display Series P4/ P5/ P6/ P6.67/
P8/ P10 (DIP)/ P10 (SMD)/ P10.4/ P12/ P16
2. Outdoor Strip/Louver LED Display Series P15.625-15.625/
P15.625-31.25/ P31.25-31.25
3. Outdoor Rental LED display Series P3.9/ P4.8/ P5/ P6/ P6.25/
P6.67/ P6.94/ P7.8/ P8/ P8.9/ P10
4. Indoor Fix Installation LED display Series P1.2/P1.56/P1.6/
P1.667/ P1.8/ P1.875/ P1.9/ P2/ P2.5/ P3/
P3.9/ P4/ P4.8/ P5/ P6/ P6.67/ P7.62/ P8/ P10
5. Indoor Rental LED Display Series P2/ P2.5/ P3/ P3.125/ P3.75/
P3.91/ P4/ P4.81/ P5/ P6/
P6.25/ P6.4/ P7.62/ P8/ P10
6. Transparent LED Display Series P3.9-7.8/ P7.8-15.625/ P8/ P10
7. Floor LED Display Series P6.25/ P6.25 interactive floor LED
display /P8.9/ P10.4
8. Perimeter LED Display Series P6/ P8/ P10/ P12/ P16
9. LED Advertising Player/Kiosk LED Display Series P2.5/ P3/ P4/
P5/ P5.3/ P6
10. Taxi/Bus Mounted LED Display Series P4/ P5/ P6/ P7.62
11. LED Ball Display Series P3/ P4/ P5/ P6/ P7.62/ P8/ P10
12. Multiple creative LED displays and DJ booth LED displays for
clubs and stages.
• Stair LED displays: P6/ P6.67/ P7.62/ P10/ P16/ P18/ P20
• Led Street Screen: p4/p5/p6/p8
• LED Floor Tiles: P6.25/ P8.9/ P10.4
• Led Stage Screen-DJ screen: P3/ P4 /P5/ P6
• More customized LED displays.
We will be your best partner by providing you professional LED
display products and service and support from China production
base!! Should any LED display projects, please just feel free to
contact!
