P10 Outdoor DIP LED Screen,P10 DIP 1R1G1B Outdoor Full Color led
display,brightness 8000nits
Arise Technology Co., Ltd
Web:http://www.ariseled.com
QQ:1327078259 Skype:ariseled
http://i.youku.com/ariseled
info@ariseled.com
Outdoor LED Display DIP Series:
P10 DIP 1R1G1B Outdoor LED Display
P12 DI1R1G1B Outdoor LED Display
P16 DIP 1R1G1B Outdoor LED Display
P16 DIP 2R1G1B Outdoor LED Display
P20 DIP 1R1G1B Outdoor LED Display
P20 DIP 2R1G1B Outdoor LED Display
P25 DIP 2R1G1B Outdoor LED Display
Product features
High brightness, low power consumption, long service life, stable
performance, less maintenance
Box size can be customized, flexible and changeable
Installation is simple, easy to maintain, easy to use
Application range
Widely used in large venues, stadiums, banks, post and
telecommunications, government agencies, terminal, docks, stations,
securities market and other market transactions, medical systems,
power, and the exhibition hall a need for publicity, advertising,
information release guidance and other places.
Pixel structure | Outdoor lamp LED |
LED Specification | DIP346 |
Pitch composing | 1R1G1B |
Pixel distance | 10mm |
Module resolution (W×H) | 32×16 dot |
Module size | 320mm×160mm |
Pixel density | 10000 dot |
Peak power consumption | 30W |
Module weight | 0.785Kg |
White balance brightness | 7500cd/m² |
The best distance of visualization | ≥ 10m |
Horizontal perspective | 120° |
Vertical perspective | 120° |
Luminance uniformity | ≥97% |
Color uniformity | ±0.003Cx,Cy |
Contrast | 3000:01:00 |
Maximum power | 586W/m² |
Average power | 176 W/m² |
Input voltage | AC220V(50Hz) |
Output voltage | DC 5V |
Drive mode | 1/4 Scan |
Frame frequency | 60Hz |
Refresh rate | ≥1920 Hz |
Control way | Synchronous |
Typical life values | 50000 hrs |
Working temperature range | -10~40℃ |
Storage temperature range | -20~60℃ |
Working humidity range (RH) | 10-80% |
Storage humidity range (RH) | 10-85% |
Arise Technology Co., Ltd. is a high-tech company dedicated in
providing professional LED displays and comprehensive
optoelectronic solutions.
Arise Technology owns strong execution, brilliant development
strategies and programs, sustainable creation based on market
demand. We spare no effort to provide customers with
market-oriented innovative products with good reliability, suitable
solutions and all-round service. Our main products includes indoor
and outdoor full color fixed installation LED display, indoor and
outdoor rental LED displays, LED Mesh/LED curtain displays, LED
advertising player displays, floor LED displays, stadium/perimeter
LED displays, creative LED displays, mobile LED displays, flexible
LED displays, transparent LED displays, high-resolution full color
LED display, customized LED displays, and the whole display system
and equipment. We are ready to providing LED display solutions for
oversea and domestic advertisement media, building advertising and
lighting, municipal administration, hospital, hotel, bank, traffic,
sports, entertainment, show, exhibition, etc.
We Arise Technology regard integrity in company staff, customers
and suppliers as the enterprise foundations, market demands as the
guide. We guarantee quality with profession and dedication and use
enterprise culture to fill our brand. We keep striving, forging
ahead, creating to provide customer with strong and unremitting
support and backup.
We Arise Technology also have more LED displays for your projects:
Category Pixel Pitch(mm)
1. Outdoor Fix Installation LED Display Series P4/ P5/ P6/ P6.67/
P8/ P10 (DIP)/ P10 (SMD)/ P10.4/ P12/ P16
2. Outdoor Strip/Louver LED Display Series P15.625-15.625/
P15.625-31.25/ P31.25-31.25
3. Outdoor Rental LED display Series P3.9/ P4.8/ P5/ P6/ P6.25/
P6.67/ P6.94/ P7.8/ P8/ P8.9/ P10
4. Indoor Fix Installation LED display Series P1.2/P1.56/P1.6/
P1.667/ P1.8/ P1.875/ P1.9/ P2/ P2.5/ P3/
P3.9/ P4/ P4.8/ P5/ P6/ P6.67/ P7.62/ P8/ P10
5. Indoor Rental LED Display Series P2/ P2.5/ P3/ P3.125/ P3.75/
P3.91/ P4/ P4.81/ P5/ P6/
P6.25/ P6.4/ P7.62/ P8/ P10
6. Transparent LED Display Series P3.9-7.8/ P7.8-15.625/ P8/ P10
7. Floor LED Display Series P6.25/ P6.25 interactive floor LED
display /P8.9/ P10.4
8. Perimeter LED Display Series P6/ P8/ P10/ P12/ P16
9. LED Advertising Player/Kiosk LED Display Series P2.5/ P3/ P4/
P5/ P5.3/ P6
10. Taxi/Bus Mounted LED Display Series P4/ P5/ P6/ P7.62
11. LED Ball Display Series P3/ P4/ P5/ P6/ P7.62/ P8/ P10
12. Multiple creative LED displays and DJ booth LED displays for
clubs and stages.
• Stair LED displays: P6/ P6.67/ P7.62/ P10/ P16/ P18/ P20
• Led Street Screen: p4/p5/p6/p8
• LED Floor Tiles: P6.25/ P8.9/ P10.4
• Led Stage Screen-DJ screen: P3/ P4 /P5/ P6
• More customized LED displays.
We will be your best partner by providing you professional LED
display products and service and support from China production
base!! Should any LED display projects, please just feel free to
contact!
