HD P2 Indoor Fullcolor SMD High Brightness Big LED Video Wall,P2mm
HD LED Display Screen Module, P2mm LED Video Wall
Panel,P1.5625mm,P1.667mm,P1.923mm,P2, P2.5
Arise Technology Co., Ltd
Web:http://www.ariseled.com
QQ:1327078259 Skype:ariseled
http://i.youku.com/ariseled
1.High refresh rate, MIB5153 FM-PWM drive IC;
2.Perfect low grey technology, 16bit grey scale;
3.Ultra-light Weight: 4.6kg/cabinet;
4.Die-cast aluminum cabinet with side lock to avoid black and white
lines;
5.4K Hight Definition TV wall.
Pixel Pitch | P1.5625mm | P1.667mm | P1.923mm | P2mm |
Encapsulation | SMD1010 | SMD1010 | SMD1010 | SMD1010 |
Pixel Configuration | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B |
Driver Method | Scan 1/32 | Scan 1/30 | Scan 1/26 | Scan 1/30 |
Color Match | R:G:B=3:6:1 | R:G:B=3:6:1 | R:G:B=3:6:1 | R:G:B=3:6:1 |
Module Size(H*W) | 300mm*200mm | 300mm*200mm | 300mm*200mm | 300mm*200mm |
Module Resolution(H*W) | 192*128dots | 180*120dots | 156*104dots | 150*100dots |
Cabinets Size(H*W) | 300*400mm | 300*400mm | 300*400mm | 300*400mm |
Pixel Density(Pixels/M2) | 409600 | 360000 | 270400 | 250000 |
Cabinet Weight | 4.6kg | 4.6kg | 4.6kg | 4.6kg |
Cabinet Material | Die-cast Aluminum |
Maintenance | Rear/front |
Average Power Consumption | 280-520W/M2 | 237-430W/M2 | 570-820W/M2 | 320-570W/M2 |
Max. Consumption | 840W/M2 | 720W/M2 | 1500W/M2 | 940W/M2 |
Brightness | Manual or Automatic by system software |
View Angle | H 140° /V 140° |
Refresh Rate | ≥1920Hz |
Frame Frequency | ≥60Hz |
Color Depth | 16bit |
Voltage Input | AC110V/220V±15% 40~65HZ |
IP Rating | IP31 |
Operating Temperature | -20ºC~60ºC , storage for :-30ºC~+90ºC |
System Working Environment Humidity | 10%-90%RH |
Life Span(Hours) | ≥55,000Hours |
Best View Distance | 1-10meter |
Color Temperature | 5600K±500 |
Control Distance | <100meter by Internet Cable(without Relay); Fiber Cable > 500
meters |
No-malfunction time(Avg.) | >5000hours |
Control system | Linsn/Novastar |
Compliant standard | CE,.CCC. |
Information Sources | Many kinds of signal access: can input TV signals , |
DVD signals , DVI, S-VIDEO, RGB, VGA, and so on. |
Arise Technology Co., Ltd. is a high-tech company dedicated in
providing professional LED displays and comprehensive
optoelectronic solutions.
Arise Technology owns strong execution, brilliant development
strategies and programs, sustainable creation based on market
demand. We spare no effort to provide customers with
market-oriented innovative products with good reliability, suitable
solutions and all-round service. Our main products includes indoor
and outdoor full color fixed installation LED display, indoor and
outdoor rental LED displays, LED Mesh/LED curtain displays, LED
advertising player displays, floor LED displays, stadium/perimeter
LED displays, creative LED displays, mobile LED displays, flexible
LED displays, transparent LED displays, high-resolution full color
LED display, customized LED displays, and the whole display system
and equipment. We are ready to providing LED display solutions for
oversea and domestic advertisement media, building advertising and
lighting, municipal administration, hospital, hotel, bank, traffic,
sports, entertainment, show, exhibition, etc.
We Arise Technology regard integrity in company staff, customers
and suppliers as the enterprise foundations, market demands as the
guide. We guarantee quality with profession and dedication and use
enterprise culture to fill our brand. We keep striving, forging
ahead, creating to provide customer with strong and unremitting
support and backup.
We Arise Technology also have more LED displays for your projects:
Category Pixel Pitch(mm)
1. Outdoor Fix Installation LED Display Series P4/ P5/ P6/ P6.67/
P8/ P10 (DIP)/ P10 (SMD)/ P10.4/ P12/ P16
2. Outdoor Strip/Louver LED Display Series P15.625-15.625/
P15.625-31.25/ P31.25-31.25
3. Outdoor Rental LED display Series P3.9/ P4.8/ P5/ P6/ P6.25/
P6.67/ P6.94/ P7.8/ P8/ P8.9/ P10
4. Indoor Fix Installation LED display Series P1.2/P1.56/P1.6/
P1.667/ P1.8/ P1.875/ P1.9/ P2/ P2.5/ P3/
P3.9/ P4/ P4.8/ P5/ P6/ P6.67/ P7.62/ P8/ P10
5. Indoor Rental LED Display Series P2/ P2.5/ P3/ P3.125/ P3.75/
P3.91/ P4/ P4.81/ P5/ P6/
P6.25/ P6.4/ P7.62/ P8/ P10
6. Transparent LED Display Series P3.9-7.8/ P7.8-15.625/ P8/ P10
7. Floor LED Display Series P6.25/ P6.25 interactive floor LED
display /P8.9/ P10.4
8. Perimeter LED Display Series P6/ P8/ P10/ P12/ P16
9. LED Advertising Player/Kiosk LED Display Series P2.5/ P3/ P4/
P5/ P5.3/ P6
10. Taxi/Bus Mounted LED Display Series P4/ P5/ P6/ P7.62
11. LED Ball Display Series P3/ P4/ P5/ P6/ P7.62/ P8/ P10
12. Multiple creative LED displays and DJ booth LED displays for
clubs and stages.
• Stair LED displays: P6/ P6.67/ P7.62/ P10/ P16/ P18/ P20
• Led Street Screen: p4/p5/p6/p8
• LED Floor Tiles: P6.25/ P8.9/ P10.4
• Led Stage Screen-DJ screen: P3/ P4 /P5/ P6
• More customized LED displays.
