Outdoor P16 Truck Mounted LED Screens , High Definition Trailer
Mounted Led Screen
PH16 Truck Mounted LED Screen for Refresh Rate 10Hz - 3000Hz
ARISELED
p16 Truck Mounted LED Screen , Mobile led screen
Arise Technology Co., Ltd
One-stop LED display manufacturere
Web:http://www.ariseled.com
QQ:1327078259 Skype:ariseled
http://i.youku.com/ariseled
Specifications:
Part Number | P16 |
Resolution | 16(H)×8(V) |
Pixel Pitch | 16mm(Virtual:8mm) |
LED Configuration | 2R1G1B 1-BY-1 DIP |
Pixel Density | 3,906 pixels/ ㎡ |
Module Size | 256×128mm |
Cabinet Size | 1024×768mm, 768×768mm, etc. |
Driving IC | MBI5026 led & IC mounted to 2 PCB design |
Driving Method | Static State, Constant Current |
Weight | 58KG/sq.m. |
Mechanical Ratings |
Hanging Weight Support | 2T |
Surface Flatness | Gap<0.5mm |
Optical Ratings |
Brightness | >8,000cd/ ㎡ |
View Angle | 120°/60° |
Gray Scale | 8bits input, correction with 14bits |
Display COLOR | 16.7M |
Brightness Adjustment | 0～100% 10 level |
Power Supply |
Operation Power | 90～260V 50～60Hz |
Max. Power Consumption | 1200W/ ㎡ |
Average Power Consumption | 350W/ ㎡ |
Control System |
Control Mode | Synchronous display with control PC by DVI |
Frame Update Frequency | 60～85Hz |
Screen Refresh Frequency | 300～1000Hz |
Gamma Correction | -5.0～+5.0 |
Support Input | Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI |
Control Distance | Ethernet cable<120m or Fiber Optic<10Km |
Support VGA Mode | 1024×768, 1280×1024, 1600×1200, 1920×1280 |
Brightness Correction | Pixel, Module, Cabinet |
Environmental |
Operating Temperature | -20°～+60° |
Operating Humidity | 10～95% RH |
Operating Life | 100,000hours |
MTBF | 5000hours |
Protection Level | IP65 |
Out of Control Rate | <0.02% |
Description:
1.Wide application field&short ROI time:Commercial advertising
LED display, Stadium perimeter LED display,Mobile trailer LED panel
for mobile media,shopping mall LED panel for logo
showing,bank&stock exchange LED panel for rates
showing,train&bus station,air port,telecommunication LED panel
system for information showing and instruction.
2.High Contrast:7000:1,which is a very high level to ensure a vivid
image of our LED display screen system.
3. First-class LED chip: Supplied by Ni-chia of Japan to ensure the
long lifetime and high brightness of our LED screen system.
4.Clear vivid image quality even in direct, full-on sunlight to
ensure you attracts more audience to get short ROI of your LED
screen’s investment.
5.Long-term Brightness:7000-nit brightness( for outdoor full color)
(1200-2700 nits brightness for indoor full color)capacity
throughout product lifetime of the LED display.
Arise Technology owns strong execution, brilliant development
strategies and programs, sustainable creation based on market
demand. We spare no effort to provide customers with
market-oriented innovative products with good reliability, suitable
solutions and all-round service. Our main products includes indoor
and outdoor full color fixed installation LED display, indoor and
outdoor rental LED displays, LED Mesh/LED curtain displays, LED
advertising player displays, floor LED displays, stadium/perimeter
LED displays, creative LED displays, mobile LED displays, flexible
LED displays, transparent LED displays, high-resolution full color
LED display, customized LED displays, and the whole display system
and equipment. We are ready to providing LED display solutions for
oversea and domestic advertisement media, building advertising and
lighting, municipal administration, hospital, hotel, bank, traffic,
sports, entertainment, show, exhibition, etc.
We Arise Technology regard integrity in company staff, customers
and suppliers as the enterprise foundations, market demands as the
guide. We guarantee quality with profession and dedication and use
enterprise culture to fill our brand. We keep striving, forging
ahead, creating to provide customer with strong and unremitting
support and backup.
We Arise Technology also have more LED displays for your projects:
• Outdoor fix installation LED displays: P4/P4.8/P5/ P6/ P6.67/ P8/
P10 (DIP)/ P10 (SMD)/ P10.4/ P12/ P16/ P20/ P25/ P31.25/ P40/ P50;
• Indoor fix installation LED displays: P1.6/ P1.667/ P1.8/ P1.875/
P1.9/ P2/ P2.5/ P3/ P3.9/ P4/ P4.8/ P5/ P6/ P6.67/ P7.62/ P8/ P10
• Outdoor Rental LED displays: P3.9/ P4.8/ P5/ P6/ P6.25/ P6.67/
P6.94/ P7.8/ P8/ P8.9/ P10
• Indoor Rental LED displays: P2/ P2.5/ P3/ P3.125/ P3.75/ P3.91/
P4/ P4.81/ P5/ P6/ P6.25/ P6.4/ P7.62/ P8/ P10
• Perimeter LED Displays: P6/ P8/ P10/ P12/ P12.5/ P16
• LED Advertising Player/Kiosk LED displays: P2.5/ P3/ P4/ P5/
P5.3/ P6
• Stair LED displays: P6/ P6.67/ P7.62/ P10/ P16/ P18/ P20
• Transparent LED display: p3.9/p7.81/p8/p10
• Led Street Screen: p4/p5/p6/p8
• LED Floor Tiles: P6.25/ P8.9/ P10.4
• LED ball: P3/ P4/ P5/ P6/ P7.62/ P8/ P10
• Led Stage Screen-DJ screen: P3/ P4 /P5/ P6
• Taxi LED banner signs: P4/ P5/ P6
• Bus LED banner signs: P5/ P6/ P7.62
• More customized LED displays.
We will be your best partner by providing you professional LED
display products and service and support from China production
base!! Should any LED display projects, please just feel free to
contact!
