P4 Outdoor screen,P4mm outdoor fix installation LED
displays,p5,p6,p8,p10,p12mm
Arise Technology Co., Ltd. One-stop LED display manufacturere
Website: www.ariseled.com
Skype: ariseled
Email: info@ariseled.com
http://i.youku.com/ariseled
ITEM | P4 |
Pixel Pitch(㎜) | 4mm |
Pixel Density(pixel/㎡) | 62500 |
Pixel Component | 1R1G1B |
LED Configuration | SMD1921 |
Panel Dimension(W×H)㎜ | 256*128 |
Scan Mode | 1/8 |
Cabinet Dimension(W×H)㎜ | 768*768/Customized |
Cabinet Material | Iron/Customized |
Brightness(cd/㎡) | ≥6500 |
Color Temperature | 3200K-9500K |
Viewing Angle(V) | 140° |
Viewing Angle(H) | 140° |
Contrast Ratio | 3000:01:00 |
Max Power Consumption(w/㎡) | ≤1000 |
Ave Power Consumption(w/㎡) | 380 |
Operating Power Source | AC85~264V(47-63Hz) |
Frame Frequency(Frame/S) | 60 |
Refresh Rate(Hz) | ≥1200 |
Gray Level | RGB65536Grade |
Brightness Adjustment Level | 256Grade |
Brightness Adjustment Mode | Manual/Automatic/Programmable |
Control Distance | UTP＜100m；Muti Mode Fiber＜500m；Single Mode Fiber＜10Km |
Operating Temp | ﹣20℃－﹢50℃ |
Operating Humidity | 10%－90%RH |
Protecting Rating | IP65 |
MTBF | ＞10000h |
LED Life Span | ＞100000h |
LED Best View distance | 4m-150m |
Features:
1.outdoor advertising series, with the size of 960mm and 960mm, has
three kinds with the pixel pitch of 6mm, 10mm.
2.The square shape product can be composed from the LED cabinet
with the proportion of 16:9 and 4:3.
3.This LED cabinet only weighs 40kg and with depth of 100mm. That
brings the benefits for the transportation.
4.The seamless design improves the display quality.
5.Featuring high resolution and high brightness, it can keep high
contrast level even in strong sunlight.
6.The replace for modules costs few, without changing the original
structure.
7.This unit cabinet offers a cost-effective display solution for
outdoor usage.
Arise Technology Co., Ltd. is a high-tech company dedicated in
providing professional LED displays and comprehensive
optoelectronic solutions.
Arise Technology owns strong execution, brilliant development
strategies and programs, sustainable creation based on market
demand. We spare no effort to provide customers with
market-oriented innovative products with good reliability, suitable
solutions and all-round service. Our main products includes indoor
and outdoor full color fixed installation LED display, indoor and
outdoor rental LED displays, LED Mesh/LED curtain displays, LED
advertising player displays, floor LED displays, stadium/perimeter
LED displays, creative LED displays, mobile LED displays, flexible
LED displays, transparent LED displays, high-resolution full color
LED display, customized LED displays, and the whole display system
and equipment. We are ready to providing LED display solutions for
oversea and domestic advertisement media, building advertising and
lighting, municipal administration, hospital, hotel, bank, traffic,
sports, entertainment, show, exhibition, etc.Aisre LED displays are
approved by CE, RoHS and FCC certifications.
We Arise Technology regard integrity in company staff, customers
and suppliers as the enterprise foundations, market demands as the
guide. We guarantee quality with profession and dedication and use
enterprise culture to fill our brand. We keep striving, forging
ahead, creating to provide customer with strong and unremitting
support and backup.
We Arise Technology also have more LED displays for your projects:
•Outdoor fix installation LED displays: P4/P4.8/P5/ P6/ P6.67/ P8/
P10 (DIP)/ P10 (SMD)/ P10.4/ P12/ P16/ P20/ P25/ P31.25/ P40/ P50;
•Indoor fix installation LED displays: P1.6/ P1.667/ P1.8/ P1.875/
P1.9/ P2/ P2.5/ P3/ P3.9/ P4/ P4.8/ P5/ P6/ P6.67/ P7.62/ P8/ P10
•Outdoor Rental LED displays: P3.9/ P4.8/ P5/ P6/ P6.25/ P6.67/
P6.94/ P7.8/ P8/ P8.9/ P10
•Indoor Rental LED displays: P2/ P2.5/ P3/ P3.125/ P3.75/ P3.91/
P4/ P4.81/ P5/ P6/ P6.25/ P6.4/ P7.62/ P8/ P10
•Perimeter LED Displays: P6/ P8/ P10/ P12/ P12.5/ P16
•LED Advertising Player/Kiosk LED displays: P2.5/ P3/ P4/ P5/ P5.3/
P6
•Stair LED displays: P6/ P6.67/ P7.62/ P10/ P16/ P18/ P20
•Transparent LED display: p3.9/p7.81/p8/p10
•Led Street Screen: p4/p5/p6/p8
•LED Floor Tiles: P6.25/ P8.9/ P10.4
•LED ball: P3/ P4/ P5/ P6/ P7.62/ P8/ P10
•Led Stage Screen-DJ screen: P3/ P4 /P5/ P6
•Taxi LED banner signs: P4/ P5/ P6
•Bus LED banner signs: P5/ P6/ P7.62
•More customized LED displays.
We will be your best partner by providing you professional LED
display products and service and support from China production
base!! Should any LED display projects, please just feel free to
contact!
