Led electronic football scoreboards /Sport Perimeter Stadium LED display P5 P6 P8 P10 P12

    Buy cheap Led electronic football scoreboards /Sport Perimeter Stadium LED display P5 P6 P8 P10 P12 from wholesalers

    Buy cheap Led electronic football scoreboards /Sport Perimeter Stadium LED display P5 P6 P8 P10 P12 from wholesalers
    • Buy cheap Led electronic football scoreboards /Sport Perimeter Stadium LED display P5 P6 P8 P10 P12 from wholesalers

    Led electronic football scoreboards /Sport Perimeter Stadium LED display P5 P6 P8 P10 P12

    Ask Lasest Price
    Brand Name : ARISE
    Certification : ISO CE FCC ROHS
    Model Number : Led electronic football scoreboards /Sport Perimeter Stadium LED display P5 P6 P8 P10 P12
    Price : 1
    Delivery Time : 7
    Payment Terms : TT
    Supply Ability : 20000sqm/year
    • Product Details
    • Company Profile

    Led electronic football scoreboards /Sport Perimeter Stadium LED display P5 P6 P8 P10 P12

    CE RoHS ETL EMC Football Soccer Sports P8 P10 P12 P16 Wide View Curved Perimeter Screen Advertising Stadium LED Display

    led electronic football scoreboards /Sport Perimeter Stadium LED display P5 P6 P8 P10 P12 P16


    Arise Technology Co., Ltd. One-stop LED display manufacturere

    Website: www.ariseled.com

    Skype: ariseled;

    Email: info@ariseled.com;

    Mobile/WhatsApp/WeChat: 008613620209526

    Https://www.facebook.com/Arise-Technology-Co-Ltd-388635868143638/

    http://i.56.com/ariseled

    http://i.youku.com/ariseled



    Model number

    P8

    P10

    P16

    Pixel pitch

    8mm

    10mm

    16mm

    Module resolution

    32*16

    32*16

    16*16

    Module size

    256mm*128mm

    160mm*160mm

    256mm*256mm

    Pixel Density

    15625(dot/sqm)

    10000

    3906

    Brightness

    7000(cd/sqm)

    6500(cd/sqm)

    6500(cd/sqm)

    Weight

    50(kg/sqm)

    45(kg/sqm)

    52(kg/sqm)

    View angle

    140 /140

    LED configuration

    SMD 3IN1

    SMD 3IN1

    1R1G1B

    Scanning

    1/4 scan

    1/4 scan

    Static

    Max power

    1000W

    900W

    1100w

    consumption

    Warranty

    3 Years quality warranty

    Grey Scale

    16384 level

    Working voltage

    220VAC/50HZ±10%

    Life span

    >100000 hours

    Lifetime to 50%

    75,000hr

    brightness

    Temperature Range

    -20℃ to +60℃

    Service access

    Rear

    Certification

    CCC,ROHS,CE

    Grey Scale

    16384 level


    Packaging & Shipping

    1.We can offer any kinds of the standard & customized package for you/ such as: Flight case/ wooden case & paper carton. We can also help you print your logo on your package case & also the product itself.

    2.We Provide Drop shipping Service. In order to ensure you receive your order tax free upon import/ we declare lower value.

    3. For Regular standard cabinet orders/ we can ship out in 1-2 working days after receiving your sample confirmation and payment; for big customized OEM Order: we need longer time/ around 15-25 working days after receiving your sample confirmation.


    After-sale service

    1. Lifetime free maintenance and upgrade.

    2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.

    3. Customer satisfaction tracking report.

    4. Free technician training.

    5. Full set of documents free of charge/ which including installation guidance/ software operation manual/ easy maintenance manual and control system software CD and so on.


    Warranty:

    1.We will provide a sum of spare parts to you together with the shipment(the details are as above)/ it included like leds/ power supply/ modules/ cables…and so on/ and it’s enough for the replacement within 2 years.

    2.We will provide two years warranty for our products. That means two years of factory labor and components is provided for free/ however the customer should pay for the round shipping cost for broken parts.

    3. For the technical support/ we will send the installation drawings/ user manual after the order is confirmed/ and we can offer the free training for your technician in our factory until he can manage it well.

    4. For the installation/ if you need/ we can send an engineer to your country to help & instruct the installation/ but your side need to pay for the round tickets and accommodation.

    5. For future service/ if you meet any problems/ our overseas engineer will service you online or by phone in 7x24 hours.

    This is our LED display category from Arise Technology Co., Ltd. Thanks for your attention.

    Category

    Pixel Pitch(mm)

    1. Outdoor Fix Installation LED Display Series

    P4/ P5/ P6/ P6.67/ P8/ P10 (DIP)/ P10 (SMD)/ P10.4/ P12/ P16

    2. Outdoor Strip/Louver LED Display Series

    P15.625-15.625/ P15.625-31.25/ P31.25-31.25

    3. Outdoor Rental LED display Series

    P3.9/ P4.8/ P5/ P6/ P6.25/ P6.67/ P6.94/ P7.8/ P8/ P8.9/ P10

    4. Indoor Fix Installation LED display Series

    P1.2/P1.56/P1.6/ P1.667/ P1.8/ P1.875/ P1.9/ P2/ P2.5/ P3/


    P3.9/ P4/ P4.8/ P5/ P6/ P6.67/ P7.62/ P8/ P10

    5. Indoor Rental LED Display Series

    P2/ P2.5/ P3/ P3.125/ P3.75/ P3.91/ P4/ P4.81/ P5/ P6/


    P6.25/ P6.4/ P7.62/ P8/ P10

    6. Transparent LED Display Series

    P3.9-7.8/ P7.8-15.625/ P8/ P10

    7. Floor LED Display Series

    P6.25/ P6.25 interactive floor LED display /P8.9/ P10.4

    8. Perimeter LED Display Series

    P6/ P8/ P10/ P12/ P16

    9. LED Advertising Player/Kiosk LED Display Series

    P2.5/ P3/ P4/ P5/ P5.3/ P6

    10. Taxi/Bus Mounted LED Display Series

    P4/ P5/ P6/ P7.62

    11. LED Ball Display Series

    P3/ P4/ P5/ P6/ P7.62/ P8/ P10

    12. Multiple creative LED displays and DJ booth LED displays for clubs and stages.
